Fire pump system are designed as the China Standard GB 6245 and American NFPA 20. Horizontal split -case, vertical turbine centrifugal pump,end suction pump are applicable for firefighting system. With the safety, reliability, energy conservation design, NEP fire pump have obtained CE, FM approved, UL listed, CCC, CCS Certificates. Pumps are available in diesel engine and electric motor, both 50Hz and 60Hz.
Vertical Fire Pump are designed as NFPA 20.
Operating Parameters
Capacity up to 5000m³/h
Head up to 370m
Application petrochemical,municipal,power stations,
manufacturing and chemical industries,onshore & offshore platforms ,steel & metallurgy
● Number of stages will be designed upon head requirements
● Enclosed impellers, single suction
● Electrical starting
● Completely package fire pump systems are available
● Recommend material for construction are carbon steel or stainless steel for shaft, discharge head & bearing, bronze for impeller
● Performance and hydrostatic tests
● Column lengths in accordance with applications
● NFPA-20
● UL-448
● FM-1312
● Discharge flange ASME B16.5 RF
● Special design available on request
● Other materials are available on request
Also designs offshore fire pump systems with CCS certification.
Operating Parameters
Capacity up to 3168m³/h
Head up to 140m
Application petrochemical,municipal,power stations,
manufacturing and chemical industries,onshore & offshore platforms ,steel & metallurgy
●Single stage double suction horizontal split case pump
●Clockwise or counter-clockwise rotation viewed from coupling side is available
●Diesel engine starting, also electrical is available
●Packing seal as standard , mechanical seal as optional
●Grease lubricated or oil lubricated bearings are available
●Completely package fire pump systems are available
● NFPA-20
● Special design available on request
●All duplex stainless steel
●Ductile iron for pump casing and cover, stainless steel and bronze for impeller and seal ring, carbon steel/stainless steel for shaft and shaft sleeve
●Other materials are available on request
The vertical multistage jockey pump ensuring for a certain period of time, the fire pump system pressure is kept constant without starting the main pump, Usually 1% of the rated flow of the main pump is used as the flow rate of the stabilized pump, and the rated lift is 10psi higher than the lift of the main pump.
Pre-package pump system can be designed and manufactured to the requirement of the customer. These systems are cost effective, completely self-contained including fire pumps, drivers, control systems, pipework for ease installation.
Operating Parameters
Capacity 30 to 5000m³/h
Head 10 to 370m
Application petrochemical,municipal,power stations, manufacturing and chemical industries,onshore & offshore platforms ,steel & metallurgy
They can be skid mounted or housed and supplied with electric motor or diesel engine.
● Vertical and Horizontal fire pumps
● Save costs in installation
● Packaged systems are performance and hydrostatically tested at our manufacturing facility prior to shipment
● Computer and CAD Design capabilities assist you in the design of a system customs built to your specification.
● Built in accordance with NFPA 20
● Automatic or Manual Operation
● Pump with packing seal as standard
● Cooling system, fuel system, control system, exhaust system, drive system are available
● Mounted on a structural steel frame platform that can be ship to site in a single shipment
